181/198 Epoxy Resin Bushing

181/198 Epoxy Resin Bushing

Technical Parameters:

PF: 48kV/min, 79kV/min

PD: 13.2kV≤5pC, 26 .4kV≤5pC

Rated current: 630A/1250A

Capacitance value: 18 ± 2PF

Color: red, green

Sealingring:Ф73*Ф6 (inside diameter * line diameter)

181/198 Epoxy Resin Bushing
